Item specifics
Item
Type: Car Monitors Placement: In-Dash Display Size: 7" Item Size: 255mm x 111mm x 25mm Model Name: - Resolution: 480x234 Material
Type: ABS Item Weight: 855 g Place of Origin: Guangdong, China (Mainland) Warranty: 1 Year High quality TV system: PAL / NTSC Display Component: : TFT LCD Screen, 16:9 Lens Angle: : 170 Degree Resolution: : 420 TV Line Waterproof: : IP68






Adopting TFT LCD Screen, 480(W) x RGB x 234(H) Screen Resolution. Supporting two ways of video input, V1 / V2 selecting. It will turn to blue screen when no video signal. Special coating, can be isolated from small water droplets to ensure that water vapor will not get into device. It is composition of wireless system and any model of the universal or special rear view camera.   Car Monitor Specification: > Main Features:
- Car reversing back sight surveillance Blue screen when no video signal.
- PAL / NTSC auto switch.
- Rear watching: image can be changed left and right.> Wireless Rear View Camera Specification: > Main Features:
- Provide 170 degree viewable angle.
- Waterproof and work in all condition.
- At night or in dark environment, with a weak ght power night vision.
- Spring, summer, autumn and winter use without having to worry about change in temperature.
- Appcable to all types of vehicles.>

Specifications:>

Car Rear View Monitor Specifications:> Main Features:
- Car reversing back sight surveillance Blue screen when no video signal.
- PAL / NTSC auto switch.
- Rear watching: image can be changed left and right.> Display screen:
- Size: 7 inch
-
Type: TFT LCD Screen, 16:9
- Resolution: 480(W) x RGB x 234(H)=336960 Pixels > High quaty TV system: PAL / NTSC > Voltage: DC 12V / 24V> Power: 7W > Video: Support two ways of video input, V1 / V2 selecting. It will turn to blue screen when no video signal > Rear Watching: Image can be changed left and right > Video Output Level: 1Vp-p 75Ohm > Operate Mode:
- Touch keys
- Remote control > Function Keys:
- Power: Switch for power supply
- Video: V1 / V2 selecting
- Menu: Choosing brightness, color, contrast
- Voice +: Increase button
- Voice -: Reduces button
- Mode: Selecting results of display > Rear View Mirror Pinch Cp: Adjustable 60mm ~ 90mm > Dimension(L x W x D): 255mm x 111mm x 25mm > Car Rear View Camera Specifications:> Main Features:
- Provide 170 degree viewable angle.
- Waterproof and work in all condition.
- At night or in dark environment, with a weak ght power night vision.
- Spring, summer, autumn and winter use without having to worry about change in temperature.
- Appcable to all types of vehicles.> Image Feature: COMS> IR Lights: 7 pcs> TV System: PAL / NTSC> Lens Angle: 170 Degree> Resolution: 420 TV Line> Effective Pixels:
- PAL: 648 x 586, 648 x 488
- NTSC: 656 x 492, 648 x 488> Sensing Area: 4.08 x 3.12mm> Shutter Speed:
- 1 / 60 ~ 1 / 20000
- 1 / 60 ~ 1 / 5000> Min Illumination: 0.1 ~ 0.5Lux> Video Output: PCA connector, 1.0vP > P75Q> Power: 60mA> Consumption: Max 300mA with IR on> Power Supply: 12V / 24V> Waterproof: IP68> Operating Temperature: - 20 ~ + 80 Centigrade> Storage Temperature: - 40 ~ + 80 Centigrade> Net Weight: 57g> After Sales Service: 1 Year Warranty> EPC_CMO_386>

Package Include:>

1 x Monitor> 1 x Wire Harness > 1 x Remote Controller > 1 x User Manual >   4.3 Inch Color TFT LCD Parking Car Rear view Monitor Car Rearview Backup Monitor 4.3'' 2 Video Input for Reverse Camera DVD[SALE] 480 x 272 4.3 Inch TFT LCD Car Rear View Mirror Monitor Parking Rearview Monitor + 7 IR Lights Car Reverse Camera2.4GHz Wireless Car Monitor 7 Inch 800 x 480 Color TFT LCD Car Rear View Rearview Monitor + Wireless Backup Reverse Camera7 Inch Color TFT LCD MP5 Car Rear View Mirror Monitor Auto Vehicle Parking Rearview Monitor SD/USB FM Radio For Reverse Camera[SALE] Univeral 4.3 Inch Color TFT LCD Parking Car Rear View Mirror Monitor 4.3'' Rearview Monitor for Backup Reverse Camera7 Inch RGB Car Rearview Monitor Digital Display Car VCR Monitor + 120 Degree Wide Angle 7 IR Lights Car Rear View Reverse Camera7 Inch 800 x 480 RGB Car Rearview Monitor Digital Display Car VCR Monitor + Wireless Car Rear view Reverse Camera Night Vision[SALE] 4.3 Inch Color TFT LCD Car Rear view Monitor 4.3'' Parking Rearview Monitor with 2CH Video Input / 960H x 240V Resolution
Product Description
Packaging Details Unit
Type: piece
Package Weight: 0.890kg (1.96lb.)
Package Size: 10cm x 10cm x 10cm (3.94in x 3.94in x 3.94in)
