Item specifics
Talk Range: -
Type: Two Way Radio
Brand Name: Bao Feng Walkie Talkie
Type: Portable Storage Channel: 128 Is_Display: Yes Dimensions: 58 x 110 x 32mm Frequency Range: UHF 400 ~ 480MHz, VHF 136 ~ 174MHz
Model Number: UV-5R Place of Origin: Guangdong China (Mainland) Warranty: 1 Year Color: : Yellow
Brand Name: BaoFeng
BAOFENG UV-5R transceiver is a micro-miniature multiband. FM transceiver with extensive receive frequency coverage, providing local-area two-way amateur communications along with unmatched monitoring capabity. Wide / Narrow Band (25kHz / 12.5kHz); VOX function; Busy lockout function; Scanning function; Monitor function; Time-out Timer (TOT) function; LCD display; Dual display; Battery voltage display function; Channel name display and editing functions; Signal strength indicator; Keypad lock function; Built-in Led torch; Wire clone function; Emergency alarm function; Low battery alarm; Power saving function; ROGER SET; PC software programmable Main Features:
- Dual band handheld transceiver with display function menu on the display "LCD"
- DTMF encoded
- More stubborn case, more rich and enhanced features
- Commercial FM radio receiver (65MHz ~ 108MHz)
- Incorporates 105 codes "DCS" and 50 privacy codes "CTCSS" programmable
- Broadband / Narrow, selectable
- Lithium-ion battery with high capacity
- Voice companding 50 CTCSS / 104 DCS
- VFO & Memory channels scan Emergency Alarm
- Tri-color background ght selectable 0 ~ 9 grades VOX selectable
- Dual watch dual reception
- Timer transmission "TOT"programmable
- PC programming
- Selecting the Scan Mode
- Large LCD display
- Crossband reception
- Tone end of transmission
- Time-out timer
- Keypad lock
Main Functions
- "OFFSET" (frequency offset for repeater access)
- Battery saving "SAVE" / Low battery alert
- "VOX" (voice operated transmission)
- Alarm
- Dual band handheld transceiver with display function menu on the display "LCD"
- DTMF encoded
- More stubborn case, more rich and enhanced features
- Commercial FM radio receiver (65MHz ~ 108MHz)
- Incorporates 105 codes "DCS" and 50 privacy codes "CTCSS" programmable
- Broadband / Narrow, selectable
- Lithium-ion battery with high capacity
- Voice companding 50 CTCSS / 104 DCS
- VFO & Memory channels scan Emergency Alarm
- Tri-color background ght selectable 0 ~ 9 grades VOX selectable
- Dual watch dual reception
- Timer transmission "TOT"programmable
- PC programming
- Selecting the Scan Mode
- Large LCD display
- Crossband reception
- Tone end of transmission
- Time-out timer
- Keypad lock> Main Functions
- "OFFSET" (frequency offset for repeater access)
- Battery saving "SAVE" / Low battery alert
- "VOX" (voice operated transmission)
- Alarm > Built-in:
- RX CTCSS / DCS Scan
- LED Flashght> Battery Charging:
- Standby (no-load): Red LED flashes, while Green LED glows
- Charging: RED LED sodly glows
- Fully Charged: Green LED sodly glows
- Error: RED LED flashes, while Green LED glows> Selectable Frequency Step 2.5 / 5/ 6.25 / 10 / 12.5 / 25 kHz> Frequency Range: 65MHz ~ 108MHz (only commercial FM radio reception) UHF 400 ~ 480MHz, VHF 136 ~ 174MHz (dual band)> Channel Capacity: 128> Frequency Stabity: 2.5ppm> RF Power Output: 4W / 1W> Type of Modulation: FM> Spurious Emission: < 60dB> FM Noise: 45dB(W) / 42dB (N) > Audio Distortion: ≤ 5%> Consumption:
- Standby: ≤ 75mA
- Reception: 380mA
- Transmission: ≤ 1.4A> Duty cycle: 03 / 03 / 54 min (Rx / Tx / Standby)> Selectivity: 60dB / 55dB> Intermodulation: 60dB> Adjacent Channel Selectivity: 60 / 65dB> Spurious Response: ≥ 65dB> Operated Voltage: 7.4V> Audio Power Output: 1000mW> Battery Capacity: 1800mAh Li-ion> Battery Life: About 12 hours> Operated Temperature: above 20 to 60 degree celsius> Weight: 525g> Color: Yellow> Dimensions: 58 x 110 x 32mm> Package Size (L x W x H): 180 x 142 x 95mm> Note:
1. Using rechargeable walkie-talkie for the first time, please charge for 16 hours
2.Turn off your computer before removing the battery
3. Please do not use hand to pick up the antenna, hold the antenna will affect the effective wireless intercom call range
4. Use the walkie-talkie, you should keep it vertical distance of 5.0 to 7.0 cm, and keep your face
5. Please try to use while driving handsfree speaker and the closing words
6. Keep your intercom televisions, computer monitors and other screen to maintain a distance greater than 10cm, to avoid being magnetized
7. The interphone Do things together with other metal-containing storage
8. Walkie-talkies may interfere with some hearing aids, with your hearing aid manufacturer to discuss alternatives
9. Try to place in the medical walkie-talkie off, so as not to affect the use of medical equipment
10. Do not use in airports and on aircraft. If so, prohibited driving the car to the side of the road and then
11. In potentially explosive areas must remain shut down, unless it is dedicated intercom dangerous areas (for example, Factory Mutual, CAS, or UL certified)
12. To avoid electromagnetic interference / compatibity confcts, in some cases posted notices require you to turn off the intercom, please observe> Approved: CE / FCC> After Sales Service: 1 Year Warranty> EPC_SEC_021>
Product Description
Packaging Details Unit
Type: piece
Package Weight: 0.550kg (1.21lb.)
Package Size: 11cm x 11cm x 11cm (4.33in x 4.33in x 4.33in)
Talk Range: -
Type: Two Way Radio
Brand Name: Bao Feng Walkie Talkie
Type: Portable Storage Channel: 128 Is_Display: Yes Dimensions: 58 x 110 x 32mm Frequency Range: UHF 400 ~ 480MHz, VHF 136 ~ 174MHz
Model Number: UV-5R Place of Origin: Guangdong China (Mainland) Warranty: 1 Year Color: : Yellow
Brand Name: BaoFeng
BAOFENG UV-5R transceiver is a micro-miniature multiband. FM transceiver with extensive receive frequency coverage, providing local-area two-way amateur communications along with unmatched monitoring capabity. Wide / Narrow Band (25kHz / 12.5kHz); VOX function; Busy lockout function; Scanning function; Monitor function; Time-out Timer (TOT) function; LCD display; Dual display; Battery voltage display function; Channel name display and editing functions; Signal strength indicator; Keypad lock function; Built-in Led torch; Wire clone function; Emergency alarm function; Low battery alarm; Power saving function; ROGER SET; PC software programmable Main Features:
- Dual band handheld transceiver with display function menu on the display "LCD"
- DTMF encoded
- More stubborn case, more rich and enhanced features
- Commercial FM radio receiver (65MHz ~ 108MHz)
- Incorporates 105 codes "DCS" and 50 privacy codes "CTCSS" programmable
- Broadband / Narrow, selectable
- Lithium-ion battery with high capacity
- Voice companding 50 CTCSS / 104 DCS
- VFO & Memory channels scan Emergency Alarm
- Tri-color background ght selectable 0 ~ 9 grades VOX selectable
- Dual watch dual reception
- Timer transmission "TOT"programmable
- PC programming
- Selecting the Scan Mode
- Large LCD display
- Crossband reception
- Tone end of transmission
- Time-out timer
- Keypad lock
Main Functions
- "OFFSET" (frequency offset for repeater access)
- Battery saving "SAVE" / Low battery alert
- "VOX" (voice operated transmission)
- Alarm
Specifications:>
Model: Baofeng UV-5R> Main Features:- Dual band handheld transceiver with display function menu on the display "LCD"
- DTMF encoded
- More stubborn case, more rich and enhanced features
- Commercial FM radio receiver (65MHz ~ 108MHz)
- Incorporates 105 codes "DCS" and 50 privacy codes "CTCSS" programmable
- Broadband / Narrow, selectable
- Lithium-ion battery with high capacity
- Voice companding 50 CTCSS / 104 DCS
- VFO & Memory channels scan Emergency Alarm
- Tri-color background ght selectable 0 ~ 9 grades VOX selectable
- Dual watch dual reception
- Timer transmission "TOT"programmable
- PC programming
- Selecting the Scan Mode
- Large LCD display
- Crossband reception
- Tone end of transmission
- Time-out timer
- Keypad lock> Main Functions
- "OFFSET" (frequency offset for repeater access)
- Battery saving "SAVE" / Low battery alert
- "VOX" (voice operated transmission)
- Alarm > Built-in:
- RX CTCSS / DCS Scan
- LED Flashght> Battery Charging:
- Standby (no-load): Red LED flashes, while Green LED glows
- Charging: RED LED sodly glows
- Fully Charged: Green LED sodly glows
- Error: RED LED flashes, while Green LED glows> Selectable Frequency Step 2.5 / 5/ 6.25 / 10 / 12.5 / 25 kHz> Frequency Range: 65MHz ~ 108MHz (only commercial FM radio reception) UHF 400 ~ 480MHz, VHF 136 ~ 174MHz (dual band)> Channel Capacity: 128> Frequency Stabity: 2.5ppm> RF Power Output: 4W / 1W> Type of Modulation: FM> Spurious Emission: < 60dB> FM Noise: 45dB(W) / 42dB (N) > Audio Distortion: ≤ 5%> Consumption:
- Standby: ≤ 75mA
- Reception: 380mA
- Transmission: ≤ 1.4A> Duty cycle: 03 / 03 / 54 min (Rx / Tx / Standby)> Selectivity: 60dB / 55dB> Intermodulation: 60dB> Adjacent Channel Selectivity: 60 / 65dB> Spurious Response: ≥ 65dB> Operated Voltage: 7.4V> Audio Power Output: 1000mW> Battery Capacity: 1800mAh Li-ion> Battery Life: About 12 hours> Operated Temperature: above 20 to 60 degree celsius> Weight: 525g> Color: Yellow> Dimensions: 58 x 110 x 32mm> Package Size (L x W x H): 180 x 142 x 95mm> Note:
1. Using rechargeable walkie-talkie for the first time, please charge for 16 hours
2.Turn off your computer before removing the battery
3. Please do not use hand to pick up the antenna, hold the antenna will affect the effective wireless intercom call range
4. Use the walkie-talkie, you should keep it vertical distance of 5.0 to 7.0 cm, and keep your face
5. Please try to use while driving handsfree speaker and the closing words
6. Keep your intercom televisions, computer monitors and other screen to maintain a distance greater than 10cm, to avoid being magnetized
7. The interphone Do things together with other metal-containing storage
8. Walkie-talkies may interfere with some hearing aids, with your hearing aid manufacturer to discuss alternatives
9. Try to place in the medical walkie-talkie off, so as not to affect the use of medical equipment
10. Do not use in airports and on aircraft. If so, prohibited driving the car to the side of the road and then
11. In potentially explosive areas must remain shut down, unless it is dedicated intercom dangerous areas (for example, Factory Mutual, CAS, or UL certified)
12. To avoid electromagnetic interference / compatibity confcts, in some cases posted notices require you to turn off the intercom, please observe> Approved: CE / FCC> After Sales Service: 1 Year Warranty> EPC_SEC_021>
Accessories:>
1 x Antenna> 1 x Li-ion Battery Pack> 1 x Li-ion Charger> 1 x Belt Cp> 1 x The Sng> 1 x Earpiece> 1 x User Manual> Sale!!! BaoFeng UV-5R Walkie Talkie Dual Band Transceiver 136-174Mhz & 400-480Mhz Two Way Radio with Battery free earphoneBAOFENG UV-5RE New Version Walkie Talkie Two 2 Way Radio Dual Band Transceiver VHF 136-174 / UHF 400-480MhzBaofeng A-52 Dual Band VHF 136 - 174 / UHF 400 - 520 MHz Walkie Talkie Two 2 Way Radio FM Transceiver with BatteryBaofeng UV-82 Dual Band VHF 136 - 174 / UHF 400 - 520 MHz FM Transceiver Walkie Talkie Two 2 Way Radio with Battery EarphoneBaoFeng 2 Way Radio Walkie Talkie Dual Band Two Way Radio Transceiver VHF 136-174MHz / UHF 400-480Mhz Dual Watch & ReceptionBAOFENG UV-5RT 128CH Walkie Talkie Two 2 Way Radio Dual Band VHF 136-174 / UHF 400-520MHz Portable Handheld TransceiverProduct Description
