Item specifics
Brand Name: - Display Screen Size(inch): 7 Answering Mode: Handheld Camera Sensor type: CMOS Connection Method: Wired
Model Number: - Warranty: 1 year Place of Origin: Guangdong, China (Mainland) Screen: : 7 inch TFT LCD ( 16 : 9 Display )




This 7" color display video door phone adopted aluminum alloy panel of indoor unit, fashionable and luxury. Water and oxidation-proof, durable aluminum alloy made outdoor station. Supports 500 ID cards, suitable most of the electronics lock, with delay unlocks function. Very easy to install.
Main Features: - Aluminum alloy panel of indoor unit, fashionable and luxury.
- Water and oxidation-proof, durable aluminum alloy made outdoor station
- The camera could be high definition
- 7" colorful LCD display, no radiation, low power consumption and high definition
- Monitor, intercom, unlock, wireless control, code unlock, hand free, monitors talks to monitor
- Easy operation
- Support 500 ID card
- Wireless unlocks distance: 5 - 10m
- Suitable most of the electronics lock, with delay unlocks functions.
- Volume, brightness and contrast adjustable
- Indicate ghts, built-in buzzer
- Wide appcations such as villas, apartments, office, hotels, pubc buildings, etc.
Function: - Visitors Calls
- Answering the visitors call from installed monitor
- Viewing the outside ( 60 seconds duration )
- Unlock function
- Intercom calls
Specifications:>
Main Features: - Aluminum alloy panel of indoor unit, fashionable and luxury.
- Water and oxidation-proof, durable aluminum alloy made outdoor station
- The camera could be high definition
- 7" colorful LCD display, no radiation, low power consumption and high definition
- Monitor, intercom, unlock, wireless control, code unlock, hand free, monitors talks to monitor
- Easy operation
- Support 500 ID card
- Wireless unlocks distance: 5 - 10m
- Suitable most of the electronics lock, with delay unlocks functions.
- Volume, brightness and contrast adjustable
- Indicate ghts, built-in buzzer
- Wide appcations such as villas, apartments, office, hotels, pubc buildings, etc.>
Function: - Visitors Calls
- Answering the visitors call from installed monitor
- Viewing the outside ( 60 seconds duration )
- Unlock function
- Intercom calls>
Outdoor Camera Specifications: - Input: AC 100 ~ 240V 50 / 60Hz
- Output: DC 15V / 2A
- Camera: COMS 420TVL
- LED: 6pcs
- Power Consumption: Standby 2W, unlock 12W
- Vad distance: 80m
- Viewing Angle: 92 degree
- Working Temperature: - 10C ~ + 50C
- Dimensions: 163 x 110 x 65mm
- Net weight: 334g>
Indoor Monitor Specifications: - Screen: 7 inch TFT LCD ( 16 : 9 Display )
- Input: AC 100 ~ 240V 50 / 60Hz
- Output: DC 15V / 2A
- Vad area: 154.08 ( H ) x 86.58 ( V )
- Power Consumption: Standby 2W, unlock 12W
- Talk time: About 120s
- Monitor time: About 60s
- Working Temperature: - 10C ~ + 50C
- Dimension: 240 x 170 x 25mm
- Net Weight: 462g> Operating Temperature: - 10C ~ + 55C > Operating Humidity: < 85%>
Package Size: 280 x 120 x 185mm>
Package Weight: 1491g> Attention:
- Don't put visible intercom system near the high-intensity magnetic field
- Don't spear sprinkle or spurt water or other quid directly to the visible intercom system
- Don't thump the indoor or outdoor machine
- Don't put the system under the blazing sun for a long time or under the strong reflection ne
- Please unplug your power cord when you don't use it for a long time> Approved: CE / FCC> After Sales Service: 1 Year Warranty> EPC_ACA_028>
Accessories:>
1 x User Manual> 5 x ID Card> 1 x Remote Control> 1 x Mounting Plate > 8 x Screw > 2 x Adapter> 2 x 4-Core connection cable> 1 x 3-Core Connection Cable> 1 x 2-Core Connection Cable> 1 x 6P Cable> 1 x rain cover>
Product Description
Packaging Details Unit
Type: piece
Package Weight: 1.810kg (3.99lb.)
Package Size: 10cm x 10cm x 10cm (3.94in x 3.94in x 3.94in)
